Compatibility | Hub Plus Hub 2 Hub 2 Plus ReX ReX 2 |
Sensing element | IR sensor, 2 on each side |
Motion detection distance | 4 to 15 meters (on each side, depends on settings) |
Detection angle, horizontal | 4.5° |
Possibility to deviate the horizontal viewing angle | Yes, by 3° |
Motion detection speed | From 0.3 to 2 m/s |
Pet immunity option | Yes. The detector ignores animals up to 80 centimeters in height when installed and set up correctly |
Near area detection | + |
Protection against false triggering | + |
Tamper protection | + |
Protection against masking | + |
Installation | Outdoors and indoors |
Radio communication protocol | Jeweller |
Radio frequency band | 866.0 – 866.5 MHz 868.0 – 868.6 MHz 868.7 – 869.2 MHz 905.0 – 926.5 MHz 915.85 – 926.5 MHz 921.0 – 922.0 MHz Depends on the region of sale. |
Maximum radio signal strength | 6.35 mW (limit up to 20 mW) |
Radio signal modulation | GFSK |
Radio signal range | Up to 1,700 m (without obstacles) |
Power supply | 2 CR123 batteries, 3 V |
Battery life | Up to 4 years |
Protection class | IP54 |
Operating temperature range | From -25°C to +60°C |
Operating humidity | Up to 95% |
Dimensions | 174 × 123 × 88 mm |
Weight | 615 g |
MTBF | 10 years |
