Compatibility | Hub Plus Hub 2 Hub 2 Plus ReX ReX 2 |
Color | Black White |
Installation | Indoor only |
Keypad type | Touch-sensitive |
Sensor type | Capacitive |
Contactless access | DESFire EV1, EV2 ISO14443-А (13.56 MHz) |
Tamper protection | Yes |
Password guessing protection | Yes. The keypad is locked for the time set in the settings if an incorrect password is entered three times |
Protection against attempts to use not bound to the system pass/tag | Yes. The keypad is locked for the time defined in the settings |
Radio communication protocol with hubs and range extenders | Jeweller |
Radio frequency band | 866.0 – 866.5 MHz 868.0 – 868.6 MHz 868.7 – 869.2 MHz 905.0 – 926.5 MHz 915.85 – 926.5 MHz 921.0 – 922.0 MHz Depends on the region of sale. |
Radio signal modulation | GFSK |
Maximum radio signal strength | 6.06 mW (limit up to 20 mW) |
Radio signal range | Up to 1,700 m (without obstacles) |
Power supply | 4 lithium batteries AA (FR6). Voltage 1.5V |
Battery life | Up to 3.5 years (if pass/tag reading is enabled) Up to 4.5 years (if pass/tag reading is disabled) |
Operating temperature range | From -10°C to +40°C |
Operating humidity | Up to 75% |
Dimensions | 165 × 113 × 20 mm |
Weight | 267 g |
MTBF | 10 years |
