Camera

Image Sensor

1/3” 3Megapixel progressive scan CMOS

Effective Pixels

2048(H) x 1536(V)

RAM/ROM

512MB/16MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

2.1mm:

0.06Lux/F2.2 ( Color,1/3s,30IRE)

0.35Lux/2.2 ( Color,1/25s,30IRE)

0Lux/F2.2 (IR on)

2.8mm, 3.6mm:

0.04Lux/F2.0 ( Color,1/3s,30IRE)

0.25Lux/2.0 ( Color,1/25s,30IRE)

0Lux/F2.0 (IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 20m (65ft)

IR On/Off Control

Auto/ Manual

IR LEDs

2

Lens

Lens Type

Fixed

Mount Type

Board-in

Focal Length

2.1mm (2.8mm, 3.6mm optional)

Max. Aperture

F2.2 (F2.0, F2.0)

Angle of View

H: 121° (86°, 64°), V: 87° (62°, 50°)

Optical Zoom

N/A

Focus Control

Fixed

Close Focus Distance

0.4m (0.7m, 1.3m)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.1 mm

38m(124ft)

15m(49ft)

7m(23ft)

4m(13ft)

2.8 mm

50m(164ft)

20m(65ft)

10m(33ft)

5m(16ft)

3.6 mm

72m(236ft)

29m(95ft)

14m(46ft)

7m(23ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0˚~360˚; Tilt:±40˚; Rotation:0˚~360˚

Intelligence

Event Trigger

Motion detection, Video tampering, Scene changing,

Network disconnection, Ip address conflict, Illegal

access, Storage anomaly

IVS

Tripwire, Intrusion, Object Abandoned/Missing

Advanced Intelligent Functions

Face Detection

Video

Compression

H.265/H.264H/MJPEG(Sub Stream)

Smart Codec

Support H.265+/H.264+

Streaming Capability

3 Streams

Resolution

3M(2048×1536)/1080P(1920×1080)/1.3M(1280×960)/

720P(1280×720)/D1(704×576/704×480)/

VGA(640×480)/CIF(352×288/352×240)

Frame Rate

Main Stream: 3M(1~25fps)

Sub Stream 1: D1(1~25fps)

Sub Stream 2: 1080P(1~7fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 32~10240Kbps

H.265: 12~8960Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / DWDR

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

N/A

Smart IR

Support

Defog

N/A

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/G.711Mu/AAC/ G.726

Network

Ethernet

M12 Connector (10/100Base-T)

Protocol

HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;

FTP;DHCP;DNS;DDNS;PPPoE;IPV4/V6;QoS;UPnP;

NTP;Bonjour;IEEE 802.1X;Multicast;ICMP;IGMP;TLS;

Interoperability

ONVIF Profile S&G, API

Streaming Method

Unicast / Multicast

Max. User Access

10 Users /20 Users

Edge Storage

NAS

Local PC for instant recording

Mirco SD card 128GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

E-mark(ECE-Regulation No.10)

EN50155(Environment)

Interface

Video Interface

N/A

Audio Interface

1 Built-in Mic

RS485

N/A

Alarm

N/A

Electrical

Power Supply

DC 12V (M12 Connector)

Power Consumption

< 4W

Environmental

Operating Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Stroage Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Ingress Protection

N/A

Vandal Resistance

N/A

Construction

Casing

Metal

Dimensions

Φ77.16mm×72.27mm (Φ3.03”×2.84”)

Net Weight

0.25Kg (0.55lb)

Gross Weight

0.37Kg (0.81lb)
