Specification

I/O Interface

Power

DC 5V

Ethernet

8*RJ45 10/100/1000Mbps Ports

Performance

Switching Capacity

16Gbps

Throughput

11.9Mpps

Packet Buffer

2.5M

MAC Address

1K

Jumbo Frame

2K

Transfer Mode

Store and forward

MTBF

100000 hour

Standard

Network protocol

IEEE802.3 (10Base-T)

IEEE802.3u (100Base-TX)

IEEE802.3ab (1000Base-TX)

IEEE802.3x (Flow control)

Industry Standard

EMI: FCC Part 15 CISPR (EN55032) class A

EMS: EN61000-4-2 (ESD)

EN61000-4-4 (EFT)

EN61000-4-5(Surge)

Network Medium

10Base-T: Cat3,4,5 or above UTP(≤100m)

100Base-TX: Cat5 or above UTP(≤100m)

1000Base-TX: Cat5 or aboveUTP(≤100m)

Protection

Security Certificae

CE、FCC、RoHS

Environment

Working Environment

Working Temperature: -10~50°C

Storage Temperature: -40~70°C

Working Humidity: 10%~90%, non-condensing

Storage Temperature: 5%~90%, non-condensing

Working Height: Maximum 10,000 feet

Storage heigh: Maximum 10,000 feet

Mechanical

Structure Size

Product Size: 137*77*25mm

Package Size: 175*120*63mm

Product Net-Weight: 0.3kg

Product Gross-Weight: 0.5kg

Packing Info

MEAS: 505*320*400mm

Packing Qty: 40 unit

Packing weight: 21KG

Power Voltage

Power Input Voltage: AC 100-240 V

Switch Input Voltage: DC5V1A

Package List

Switch 1 pcs, Power cord 1 pcs, User manual 1 pc, Warranty card 1 pc

Indication

DIP Switch

VLAN: Port Isolation, 1-6 ports are isolated each other, all communicate with uplink port 7/8;

Default: Default mode, Support loop alarm;

Extend: Monitor Mode, 1-6 ports support 100M speed reduction negotiation, support 250 meters in 10Mbps mode,  port 7 and port 8 as uplink port；

LED Indicators

PWR、Loop、Link
