Specification

I/O Interface

Power

Input: AC 100-240V, 50/60Hz

Ethernet

4*10/100M PoE Ports

2 *100M Ethernet Uplink Ports

Performance

Switching Capacity

1.2Gbps

Forwarding Rate

0.8928Mpps

Packet Buffer

448K

MAC Address

2K

Jumbo Frame

2048bytes

Transfer Mode

Store and forward

MTBF

100000  hours

Standard

Network protocol

IEEE802.3 (10Base-T)

IEEE802.3u (100Base-TX)

IEEE802.3x (Flow control)

PoE Protocol

IEEE802.3af (15.4W)

IEEE802.3at (30W)

Industry Standard

EMI: FCC Part 15 CISPR (EN55032) class A

EMS: EN61000-4-2 (ESD)、EN61000-4-4 (EFT)、EN61000-4-5 (Surge)

Network Medium

10BASE-T: Cat 3、4、5 UTP(≤100 meter)

100BASE-TX: Cat5 or above UTP (≤100 meter)

1000Base-TX : Cat5 or above UTP(≤100 meter)

Protection

Certificate

CE、FCC、RoHS

Environment

Environment

Working Temperature:-10~50°C

Storage Temperature:-40~70°C

Working Humidity :10%~90%，non-condensing

Storage Temperature:5%~90%，non-condensing

Working Height:Maximum10,000 feet

Storage height:Maximum 10,000 feet

Physical Features

Dimension

Product Dimension (L*W*H): 200mm*118mm*44mm

Package Dimension (L*W*H): 245mm*190mm*60mm

N.W:0.6kg

G.W:0.9kg

Packing Info

Carton MEAS: 505*320*402mm

Packing Qty: 20 units

Packing Weight:19KG

Power Voltage

Input Voltage: AC 100-240 V

Power supply: 52V1.25A

Package List

Switch 1 pcs, Power cord 1 pcs, User manual 1 pc, Certification1 pc

Indicators

DIP Switch

VLAN: Port Isolation, 1-4 port is isolated each other, but all can communicate with uplink port 5-6

Genius PoE: Enable the PoE Watchdog and port Priority(Priority (port1>port2>port3>port4), the port at the front of the sequence is first powered by PoE and data transmit

Extend: Extend Mode, support 250 meters transmission on 10Mbps

LEDs

PWR(power supply) , Green(Link&Data) , Yellow(PoE/1000M) , Power Display , DIP
