Specification

I/O Interface

Power

Input: AC 100-240V, 50/60Hz

Ethernet

8 Port 10/100M PoE + 2 Port 100M Ethernet Uplink

Performance

Switching Capacity

2Gbps

Forwarding Rate

1.488Mpps

Packet Buffer

448K

MAC Address

1K

Jumbo Frame

2048bytes

Transfer Mode

Store and forward

MTBF

100000  hours

Standard

Network protocol

IEEE802.3 (10Base-T)

IEEE802.3u (100Base-TX)

IEEE802.3x (Flow control)

PoE Protocol

IEEE802.3af (15.4W)

IEEE802.3at (30W)

Industry Standard

EMI: FCC Part 15 CISPR (EN55032) class A

EMS: EN61000-4-2 (ESD)、EN61000-4-4 (EFT)、EN61000-4-5 (Surge)

Network Medium

10BASE-T: Cat 3、4、5 UTP(≤100 meter)

100BASE-TX: Cat5 or above UTP (≤100 meter)

1000Base-TX : Cat5 or above UTP(≤100 meter)

Protection

Certificate

CE、FCC、RoHS

Environment4

Environment

Working Temperature: -10~50°C

Storage Temperature: -40~85°C

Working Humidity: 10%~90%，non-condensing

Storage Temperature: 5%~90%，non-condensing

Working Height: Maximum10,000 feet

Storage height: Maximum 10,000 feet

Physical Features

Dimension

Product Dimension (L*W*H): 200mm*118mm*44mm

Package Dimension (L*W*H): 245mm*190mm*60mm

N.W: 0.7kg

G.W:1 .0kg

Packing Info

Carton MEAS: 505*320*402mm

Packing Qty: 20 units

Packing Weight: 21KG

Power Voltage

Input Voltage: AC 100-240 V

Power supply: 52V2.3A

Package List

Switch 1 pcs, Power cord 1 pcs, User manual 1 pc, Certification 1 pc

Indicators

DIP Switch

VLAN: Port Isolation, 1-8 port is isolated each other, but all can communicate with uplink port 9-10, AI enable

Genius PoE: Enable the PoE Watchdog and port Priority(Priority (port1>port2>port3>port4..), the port at the front of the sequence is first powered by PoE and data transmit

Extend: Extend Mode, support 250 meters transmission on 10Mbps

LEDs

PWR(power supply) , Green(Link&Data) , Yellow(PoE/1000M) , Power Display , DIP
