Specifications

I/O Interface

Power

AC  input (100-240 V)

Ethernet

8 Port 10/100/1000M PoE

Performance

Switching Capacity

16Gbps

Throughput

11.9Mpps

Packet Buffer

1Mb

MAC Address

2K

Jumbo Frame

9216bytes

Transfer Mode

Store and forward

MTBF

100000 hour

Standard

Network Protocol

IEEE802.3 (10Base-T)

IEEE802.3u (100Base-TX)

IEEE802.3ab (1000Base-TX)

IEEE802.3x (Flow control)

PoE Protocol

IEEE802.3af (15.4W)

IEEE802.3at (30W)

IEEE802.3bt (60W)

Industry Standard

EMI:  FCC Part 15 CISPR (EN55032) class A

EMS:  EN61000-4-2 (ESD)、

EN61000-4-4 (EFT)、

IEN61000-4-5 (Surge)

Network Medium

10Base-T :  Cat3, 4, 5 or above UTP(≤100m)

100Base-TX :  Cat5  or above UTP(≤100m)

1000Base-TX :  Cat5  or above UTP(≤100m)

Protection

Security Certificae

CE、FCC、RoHS

Environment

Working Environment

Working Temperature: -10~50°C

Storage Temperature: -40~85°C

Working Humidity: 10%~90%，non-condensing

Storage Temperature: 5%~95%，non-condensing

Working Height: Maximum 10,000 feet

Storage heigh: Maximum 10,000 feet

Mechanical

Structure Size

Product Size: 200*118*44mm

Package Size: 245*190*60mm

Product Net-Weight: 0.6kg

Product Gross-Weight: 0.9kg

Packing Info

MEAS: 505*320*400mm

Packing Qty: 20 unit

Packing weight: 19 KG

Power Voltage

Input Voltage:  AC 100-240 V

Output Voltage: 52V2.3A

Package List

Switch 1 pcs, Power cord 1 pcs, User manual 1 pcs, Certification 1 pc

Indication

DIP Switch

VLAN:  Port Isolation, 1-6 port is isolated each other, but all can communicate with uplink port 7/8, AI enable

Default: Normal mode, all port can communicate with each other, The port AI mode is closed

Extend: Extend Mode, 3-6 port support 250 meters transmission on 10Mbps/s, AI enable

LED Indicators

PWR、Mode、1-8 Link&ACT
