| Model |
SL-N7316D-8MP/4K |
|
| System | Compression |
Standard H.265 |
| Main Processing Chip |
ARM Cortex A7 |
|
| OS |
Embedded Linux |
|
| Video | Network Access Bandwidth |
112Mbps |
| Input Resolution | 8MP、5MP、4MP、3MP、1080P、960P、720P real time | |
| Network Access |
16 CH IPC input |
|
| Output | HDMI×1：3840×2160/1920×1080/1280×1024/1024×768 VGA×1：1920×1080/1280×1024/1024×768 | |
| Audio | Input |
16 CH IPC audio input |
| 2-way Audio |
RCA×1 |
|
| Local Output |
RCA×1 |
|
| Record | Resolution |
8MP、5MP、4MP、3MP、1080P、960P、720P |
| Frame Rate |
25fps/30fps(PAL/NTSC） |
|
| Bite Stream |
32Kbps-10Mbps |
|
| Image Quality |
5 Level |
|
| Playback | Simultaneous Playback |
Max 16 CH |
| Network | Interface |
RJ45 10/100/1000 Mbps × 1 |
| Network Protocol | TCP/IP、PPPoE、DHCP、DNS、DDNS、UPnP、NTP、SMTP、ONVIF、GB28181 | |
| Storage | HDD |
SATA×2 |
| Max Capacity for 1 single HDD |
6T |
|
| Backup | USB Backup |
Yes |
| eSata Backup |
No |
|
| Interface | Alarm In |
4 |
| Alarm Output |
1 |
|
| Communication |
RS485×2, connect to PTZ and keyboard |
|
| Remote |
Optional |
|
| USB | USB2.0×2 (one in the front panel and the other in the rear panel) | |
| Others | Case |
1U |
| Dimensions(mm ) |
380×268×52(W×D×H ) |
|
| Power Supply |
DC12V |
|
| Consumption |
≤ 15W ( without HDD ) |
|
| Work Environment |
-10 ～ 50 ℃，10% ～ 90% humidity |
|
