Specifications |
|
|
I/O Interface |
|
|
Power |
AC 100-240V/50/60Hz |
|
Ethernet |
48 * 10/100/1000Mbps RJ45 Port |
|
4 * 10G SFP Port |
|
|
1 * RJ45 Console Port |
|
|
1 * USB Port |
|
|
Performance |
|
|
Bandwidth |
176Gbps |
|
Packet Buffer Memory |
131Mpps |
|
DDR SDRAM |
4G |
|
Flash Memory |
256M |
|
Package cache |
16Mbit |
|
MAC Address |
32K |
|
Jumbo frame |
12Kbytes |
|
VLANs |
4096 |
|
MTBF |
100000 hour |
|
Standard |
|
|
Network protocol |
IEEE 802.3：Ethernet MAC Protocol |
|
IEEE 802.3i：10BASE-T Ethernet |
|
|
IEEE 802.3u：100BASE-TX Fast Ethernet |
|
|
IEEE 802.3ab：1000BASE-T Gigabit Ethernet |
|
|
IEEE 802.3z：1000BASE-X Gigabit Ethernet (optical fiber) |
|
|
IEEE 802.3ae：10G Ethernet (optical fiber) |
|
|
IEEE 802.3az：Energy Efficient Ethernet |
|
|
IEEE 802.3ad：Standard method for performing link aggregation |
|
|
IEEE 802.3x：Flow control |
|
|
IEEE 802.1ab： LLDP/LLDP-MED (Link Layer Discovery Protocol) |
|
|
IEEE 802.1p：LAN Layer QoS/CoS Protocol Traffic Prioritization(Multicast filtering function) |
|
|
IEEE 802.1q：VLAN Bridge Operation |
|
|
IEEE 802.1x：Client/Server Access Control and Authentication Protocol |
|
|
IEEE 802.1d：STP |
|
|
IEEE 802.1s：MSTP |
|
|
IEEE 802.1w：RSTP |
|
|
Industry Standard |
EMI: FCC Part 15 CISPR (EN55032) class A |
|
EMS: EN61000-4-2 (ESD)、 |
|
|
EN61000-4-4 (EFT)、 |
|
|
EN61000-4-5 (Surge) |
|
|
Network Medium |
10BASE-T: Cat3、4、5 or above UTP(≤100 M) |
|
100BASE-TX: Cat5 or above UTP(≤100 M) |
|
|
1000BASE-TX: Cat5 or above UTP(≤100 M) |
|
|
Multi-mode Fiber: 50/125、62.5/125、100/140um |
|
|
Single-mode Fiber: 8/125、8.7/125、9/125、10/125um |
|
|
Certification |
|
|
Safety Certificate |
CE、FCC、RoHS |
|
Environment |
|
|
Working Environment |
Working Temperature：-10~50°C |
|
Storage Temperature：-40~70°C |
|
|
Working Humidity ：10%~90%，non-condensing |
|
|
Storage Temperature：5%~90%，non-condensing |
|
|
Working Height：Maximum 10,000 feet |
|
|
Storage heigh：Maximum 10,000 feet |
|
|
Indication |
|
|
LED Indicators |
PWR(Power indicator)，SYS(System lights)，Link/ACT(Link light/data light) |
|
Mechanical |
|
|
Structure Size |
Product Dimensions: 440*280*44mm |
|
Package Dimensions: 500*350*90mm |
|
|
Product N.W: 3.9KG |
|
|
Product G.W: 4.6KG |
|
|
Packing Info |
Carton Dimensions: 600*495*435mm |
|
Packing Qantity: 5Pcs |
|
|
Packing weight: 24KG |
|
|
Power Voltage |
Input Voltage: AC100-240V/50-60Hz |
|
Power supply: 12V8A |
|
|
Package List |
Ethernet switch: 1 Set、Instruction manual: 1 PCS、Certificate: 1 PCS、Power cord: 1PCS |
|
Serial cable: 1PCS、Rack ear: 1 Pairs、Operation manual CD: 1 PCS |
|
|
|
|
|
Software Function |
|
|
Basic function |
Support hardware watchdog, factory reset, system and port LED |
|
Support global information, statistical information, log information |
|
|
Support User management, alarm management, configuration management |
|
|
Support Port rate, duplex, flow control, maximum frame length configuration |
|
|
Support Port mirroring, port speed limit, port energy saving |
|
|
Layer 3 Interface |
Support Layer 3 interface |
|
Support IPv4, IPv6 address configuration |
|
|
Support ARP configuration |
|
|
Support ND configuration |
|
|
Layer 3 Routing |
Support IPv4 static routing |
|
Support IPv6 static routing |
|
|
DHCP |
Support DHCP server |
|
Support DHCP relay |
|
|
Support DHCP Snooping |
|
|
VLAN |
Support 4K VLAN |
|
Support 802.1Q VLAN，baesd on port VLAN |
|
|
SupportAccess、Trunk、Hybrid VLAN mode |
|
|
Support GVRP (VLAN registration protocol) |
|
|
Support MAC VLAN 、IP VLAN |
|
|
Support Voice VLAN |
|
|
MAC address |
Support MAC address automatic learning and aging |
|
Support Static, dynamic, filtered address table |
|
|
Security features |
Password protection |
|
Support Restrict user access based on port number, IP address, MAC address |
|
|
Support HTTPS、SSH V1/V2 |
|
|
Support VLAN-IP-MAC-PORT binding |
|
|
Support ARP detection, IP source protection, DoS protection |
|
|
Support DHCP Snooping、DHCP Attack protection |
|
|
Support 802.1X Certification |
|
|
SupportAAA (Authentication, Authorization, Accounting), Support RADIUS protocal |
|
|
Support Port security, port isolation |
|
|
Access control |
Support L2(Layer 2)～L4(Layer 4) Packet filtering function |
|
Support Port mirroring, flow rate limiting, QoS remarking |
|
|
QOS |
Support 8 port queues |
|
Support Port priority, 802.1P priority, DSCP priority |
|
|
Support SP, WRR Priority scheduling algorithm |
|
|
Spanning tree |
Support STP(IEEE 802.1d), RSTP(IEEE 802.1w) and MSTP(IEEE 802.1s) protocal |
|
Support Multi-instance, Support Aggregate interface |
|
|
Support BPDU protection |
|
|
Multicast |
Support IGMP v1/v2/v3 Snooping |
|
Support MLD v1/v2 Snooping |
|
|
Support Layer 2 multicast fast leave mechanism, querier |
|
|
Support Layer 2 IPv4 static multicast |
|
|
Support Layer 2 IPv6 static multicast |
|
|
Support IGMP v1/v2/v3 Layer 3 multicast |
|
|
Storm suppression |
Support multicast suppression |
|
Support broadcast storm suppression |
|
|
Support unknown unicast suppression |
|
|
Ring protection |
Support Ring protection |
|
Link Aggregation |
Support Static Aggregation |
|
Support LACP Dynamic Aggregation |
|
|
Support based on IP, MAC, mixed load-balancing modes |
|
|
Maximum support 8 aggregation groups (8 ports per aggregation group) |
|
|
IPv6 |
Support IPv6 Ping、IPv6 Traceroute、IPv6 Telnet |
|
Support IPv6 SSH |
|
|
Support IPv6 HTTP 、IPv6 HTTPS |
|
|
Management and Maintenance |
Support WEB Management (HTTP、HTTPS) |
|
Support CLI (Telnet, SSH V1/V2, Local serial port) |
|
|
Support SNMP V1/V2/V3 |
|
|
Support RMON V2 |
|
|
Support LLDP Device discovery |
|
|
Support SNTP Time synchronization |
|
|
Support CPU Monitoring, Memory Monitoring |
|
|
Support System log, classification warning |
|
|
Support Ping, Traceroute detection, cable detection |
|
